應用規范Application Specification

1、鍛鋼球閥符合API 608/API 6D標準

2、鍛鋼球閥符合1034/SO 14313標準

3、防火標志采用API 607標準

4、防靜電采用API608標準

5、鍛鋼符合ASME B16.34標準

6、結構長度符合ASMEIANSI B16.0-2000標準

7、法蘭尺寸符合ASME/ANSI B16.5-2003標準

8、對接焊符合ASME B16.25標準

9、試驗與檢驗符合API 598-2004

1.Forged steel ball valves,API 608/API 6D

2.Forged steel ball valves,1034/ISO 14313

3.Fire durable,API 607

4.Anti static, API 608

5. Forged steel valves, ASME B16.34

6. Face to face, SME/ANSI B16.0-2000

7. End flanges,ASME/ANSI B16.5-2003

8. Butt welding ends, ASME B16.25

9. Inspection and test, API598-2004
